Gid Type Electric High Vacuum Butterfly Valve

Short Description:

GID series electric high vacuum butterfly valve adopts rotary electric and electronic regulating valve drive device to realize the control of valve opening and closing or middle position through switching of external power supply or external input signal, so as to connect or cut off the air flow in the vacuum pipeline. Applicable working medium is air and non corrosive gas.


Product Detail

Product Tags

ACAV

Connection and dimensions (JB919)

model

(DN)

ΦD

ΦDO

ΦD1

H

B

l

B1

n-Φc

Flange standard

GID-25

25

70

55

30

163.5

22

166.5

114

4-Φ7

JB919

GID-32

32

78

64

36

167.5

22

166.5

114

4-Φ7

JB919

GID-40

40

85

70

45

171

22

166.5

114

4-Φ7

JB919

GID-50

50

110

90

55

184

22

166.5

114

4-Φ9

JB919

GID-63

63

125

105

70

196.3

26

166.5

114

4-Φ9

JB919

GID-80

8o

145

125

90

227.5

30

195

120

4-Φ9

JB919

GID-100

100

170

145

110

239.5

3o

195

120

4-Φ12

JB919

GID-125

125

195

170

135

252.5

35

195

120

4-Φ12

JB919

GID-150

150

220

195

160

284.5

35

254.5

159

4-Φ12

JB919

GID-200

200

275

250

215

311.5

40

254.5

159

4-Φ12

JB919

GID-250

250

330

300

270

340.5

45

254.5

159

8-Φ14

JB919

GID-300

300

380

350

320

363.5

55

254.5

159

8-Φ14

JB919

GID-400

400

500

465

420

420.5

60

254.5

159

8-Φ18

JB919

Connection and dimensions (GB6070)

model

(DN)

ΦD

ΦDo

ΦD1

H

B

L

B1

n-Φc

Flange standard

GID-25

25

70

55

30

163.5

22

166.5

114

4-Φ7

GB6070

GID-32

32

90

70

36

174

22

166.5

114

4-Φ9

GB6070

GID-40

40

100

8o

45

179

22

166.5

114

4-Φ9

GB6070

GID-50

50

110

90

55

184

22

166.5

114

4-Φ9

GB6070

GID-63

63

130

110

70

198

26

166.5

114

4-Φ9

GB6070

GID-80

80

145

125

90

227.5

30

195

120

8-Φ9

GB6070

GID-100

100

165

145

110

237

30

195

120

8-Φ9

GB6070

GID-125

125

200

175

135

255

35

195

120

8-Φ12

GB6070

GID-150

150

225

200

160

387

35

254.5

159

8-Φ12

GB6070

GID-200

200

285

260

215

316

40

254.5

159

12-Φ12

GB6070

GID-250

250

335

310

270

343

45

254.5

159

12-Φ12

GB6070

GID-300

300

425

395

320

388

55

254.5

159

12-Φ12

GB6070

GID-400

400

510

480

420

425

60

254.5

159

16-Φ14

GB6070
